Pneumatic Solutions

Diluted (lean and medium) phase handling

The most popular high pressure conveying method. Material moves constant flow in the pipeline to one or more intermediate or final receiver silos. Low pressure loss.

  • Performance different on-demand - 1 - 200 t / h
  • The flow rate of the material is high - 10 - 30 m /s
  • Due to the high speed transport material is ground to a fine fraction.
  • Recommended for less abrasive materials or large quantities of material conveyed and      long distances.



Pulse dense phase handling



Used to transport small amounts of abrasive material at low speed for less wear on the pipeline at short distances Material moves in a tightly compressed pulse bunches or so-called "dunes" in one or more intermediate or final receiver silos.

  • Pulsing provided by automatically controlled valves.
  • Productivity is low - up to 10 t / h
  • The flow rate of the material is low - 3 - 10 m / c
  • Also suitable for granular materials.



Benefits of dry pneumatic handling:



Reliability

- Automated system to prevent congestion – trouble-free continuous functioning.
- Transportation over long distances.
- Long life due to low speed and wear-resistant materials.
- Simplicity, full automation, integration in distributed control system DCS of the plant.
- Flexibility of technical solutions and configurations according to project.
- More than 20 years of experience in R &D in technology and know-how to improve         the efficiency.



Cost efficiency

- Low power consumption.
- High performance.
- Small footprint (small size, little space required) and lightweight equipment.
- Easy installation and the possibility of fast restructuring, addition or removal of             equipment.
- Can be retrofitted into existing and working plants.
- No loss of material during transportation.
- Direct loading into trucks, road and railway tanks.



Low operating costs due to:

- low-speed transportation
- special ceramic lining against wear
- low spare parts requirements
- minimum number of moving and wearing parts
- minimum maintenance requirements



Environmental friendliness and safety

No:

- leaks from pipes, pollution, waste and dust, clean room
- waste water thanks to the dry method of ash disposal
- hazardous moving parts
- loud noise from operation
